General Cable Nextgen Brand Optical Cable 48F 62.5/125 (CG) c(ETL)us FT6 3084997 Type OFCP PNU-ILPAS Series 08/15 1445780. 300-01 . Single reel 301m / 990ft
The concept and production of fiber optic cables has been a big part of the NextGen® Brand product line for more than a decade. As a leader in easy-to-use, field-friendly fiber optic cables, the indoor/outdoor product line has been especially well-known to users who appreciate the features it provides.Tight buffer designs allow direct termination of fibers with industry-standard connectors and techniques.
General Cable 48 Strand, MM, 62.5um, FT6, Armoured Fibre, 301m/990ft drum
CG0481PNU-ILPAS 48F 62.5 TB IND PLN INTLK ALUM
Orange outer jacket
301m/990ft drum (single reel)
Features:
- Interlock armor provides outstanding mechanical protection
- Interlock armor is flexible and easy to use
- Tight buffer provides individual fiber protection
- Sub-units are numbered for identification
Performance:
- Temperature: Storage -40˚C (-40˚F) to 70˚C ( 158˚F)
- Installation 0˚C ( 32˚F) to 50˚C ( 122˚F)
- Operating -20˚C (-4˚F) to 70˚C ( 158˚F)
- Minimum Bend Radius 20 X OD—Installation 10 X OD—In-Service
- Maximum Crush Resistance: 1,500 lbs/in (2,627 N/cm)
Applications:
Harsh premises environments requiring heavy-duty protection . ETL Type OFCP for installation in any premises location when installed in accordance with NEC article 770.154 and 770.179
Compliances:
- ETL Listed Type OFCP
- CSA FT6
- TIA 568 C.3
- ICEA S-83-596
- GR-409
- RoHS Compliant Directive 2002/95/EC
